Stainless Steel Wires

PRODUCT DESCRIPTION

Dashang Wire Mesh started from a stainless steel wire factory in 1998. We can provide different types of stainless steel wires in different applications: weaving wire, annealing wire, spring wire and welding wire.

Weaving Wire & Braiding Wire

Grade: 304, 304L, 304B/304C1, 304H, 304ES(T), 316, 316L, 321, 309S, 310S, 314, 347, 201CU, 631(J1), D668, etc.

Aplication: It can be usted in weaving general nets, heat resistance belts, and also widely used for chemical, food processing, petroleum, kitchen utensils, paper and pulp and converyer belt industries.

Chemical Compsition %
TYPE	C	Si	Mn	P	S	Ni	Cr	Mo	Cu	Others
316	0.08	1	2.00	0.045	0.030	10.0-14.0	16.0-18.0	2.00-3.00	-	-
316L	0.03	1.00	2.00	0.045	0.030	10.0-14.0	16.0-18.0	2.00-3.00	-	-
304	0.08	1.00	2.00	0.045	0.030	8.0-10.0	18.0-20.0	-	-	-
304HC	0.08	1.00	2.00	0.045	0.030	8.0-10.0	18.0-20.0	-	1.0-3.0	-
304L	0.03	1.00	2.00	0.045	0.030	8.0-11.0	18.0-20.0	-	-	-
304B	0.08	1.00	2.00	0.045	0.030	8.0-10.0	18.0-20.0	-	0.7-1.5	-
304ES(T)	0.08	1.00	2.0-4.5	0.045	0.030	6.0-8.0	16.0-18.0	0.5	2.0-3.0	N≤0.1
201CU	0.08	1.00	7.5-10.0	0.045	0.030	3.5-5.5	13.5-16.0	0.5	2.0-3.0	-
321	0.08	1.00	2.00	0.045	0.030	9.0-13.0	17.0-19.0	-	-	Ti≥5*C%
314	0.25	1.5-3.0	2.00	0.045	0.030	19.0-22.0	23.0-26.0	-	-	-
310S	0.08	1.50	2.00	0.045	0.030	19.0-22.0	24.0-26.0	-	-	-
309S	0.08	1.00	2.00	0.045	0.030	12.0-15.0	22.0-224.0	-	-	-
347	0.1	1.00	2.00	0.045	0.030	9.0-13.0	17.0-19.0	-	-	Nb: 8C-1.10
D668/204CU	0.12	1.00	11.0-15.0	0.045	0.030	1.6-2.5	12.5-14.0	0.6	1.5-2.5	N≤0.1
D667/200CU	0.12	1.00	11.0-15.0	0.045	0.030	0.5-1.5	12.5-14.0	0.6	1.5-2.5	-
430	0.12	0.75	1.00	0.045	0.030	-	16.0-18.0	-	-	-
NOTE: The single value represents the max. (Above tables)

Diameter MM	TYPE	Delivery Condition
Diameter MM	TYPE	Soft bright
0.6-0.99	316, 316L, 304, 304L, 321, 314, 310S, 309S, 347	650-800
	304B, 201CU, 304ES(T)	630-780
	304HC	600-750
	D668/204CU, D667/200CU	680-850
	430	500-600
1.0-3.49	316, 316L, 304, 304L, 321, 314, 310S, 309S, 347	620-800
	304B, 201CU, 304ES(T)	600-780
	304HC	550-750
	D668/204CU, D667/200CU	650-850
	430	460-600
3.5-10.0	316, 316L, 304, 304L, 321, 314, 310S, 309S, 347	600-800
	304B, 201CU, 304ES(T)	580-780
	304HC	520-720
	D668/204CU, D667/200CU	620-820
	430	450-600

Redrawing & Annealing Wire

Grade: 304, 304M, 304L, AISIL304L, 302, 304H, 321, 316, 316L, AISI316L, 347, 430, 430LXJ1/160, 430LXJ2/180, ETC.

Application: Supplying good elongation genratrix for other manufactures in the lines of filament drawing, producing fine spring wire,acupuncture wire and pressed wires, etc.

Chemical Compsition %
TYPE	C	Si	Mn	P	S	Ni	Cr	Mo	Cu	Others
316	0.08	1.00	2.00	0.045	0.03	10.0-14.0	16.0-18.0	2.00-3.00	-	-
316L	0.03	1.00	2.00	0.045	0.03	10.0-14.0	16.0-18.0	2.00-3.00	-	-
SUS316L	0.03	1.00	2.00	0.045	0.03	12.0-15.0	16.0-18.0	2.00-3.00	-	-
302	0.15	1.00	2.00	0.045	0.03	8.0-10.0	17.0-19.0	-	-	-
304	0.08	1.00	2.00	0.045	0.03	8.0-10.0	18.0-20.0	-	-	-
304L	0.03	1.00	2.00	0.045	0.03	8.0-11.0	18.0-20.0	-	-	-
SUS304L	0.03	1.00	2.00	0.045	0.03	9.0-13.0	18.0-20.0	-	-	-
304H	0.04-0.10	1.00	2.00	0.045	0.03	8.0-10.0	18.0-20.0	-	-	-
304M	0.06	1.00	2.00	0.045	0.03	9.0-10.0	18.0-20.0	-	-	-
321	0.08	1.00	2.00	0.045	0.03	9.0-13.0	17.0-19.0	-	-	Ti≥5*C%
347	0.1	1.00	2.00	0.045	0.03	9.0-13.0	17.0-19.0	-	-	Nb: 8C-1.10
430	0.12	0.75	1.00	0.045	0.03	-	16.0-18.0	-	-	-
430LXJ1/160	0.03	1.00	1.00	0.05	0.03	0.2-0.6	16.0-18.0	0.5	0.2-0.6	Nb: 0.3-0.7
430LXJ2/180	0.03	1.00	1.00	0.05	0.03	0.2-0.6	18.0-19.5	0.5	0.2-0.6	Nb: 0.3-0.7
NOTE: The single value represents the max. (Above tables)

Diameter MM	TYPE	Delivery Condition
Diameter MM	TYPE	Soft bright
0.6-0.99	316, 316L, SUS316L, 304, 304L, SUS304L, 304M, 321,347	600-800
	302, 304H	700-900
	430, 430LXJ1/160, 430LXJ2/180	500-600
1.0-3.49	316, 316L, SUS316L, 304, 304L, SUS304L, 304M, 321,347	580-780
	302, 304H	680-880
	430, 430LXJ1/160, 430LXJ2/180	480-600
3.5-7.99	316, 316L, SUS316L, 304, 304L, SUS304L, 304M, 321,347	550-750
	302, 304H	680-880
	430, 430LXJ1/160, 430LXJ2/180	460-600
8.0-15.0	316, 316L, SUS316L, 304, 304L, SUS304L, 304M, 321,347	550-750
	302, 304H	650-850
	430, 430LXJ1/160, 430LXJ2/180	450-600

Spring Wire

Grade: 302, 304, 304H, 321, 316, 347, 631J1, ETC

Application: Produced in accordance with the specification of JIS, with stable linearity and excellent cast and helix, it can be widely used for rolling various precision springs.

Chemical Compsition %
TYPE	C	Si	Mn	P	S	Ni	Cr	Mo	Cu	Others
316	0.08	1.00	2.00	0.045	0.03	10.0-14.0	16.0-18.0	2.00-3.00	-	-
302	0.15	1.00	2.00	0.045	0.03	8.0-10.0	17.0-19.0	-	-	-
304	0.08	1.00	2.00	0.045	0.03	8.0-10.0	18.0-20.0	-	-	-
304H	0.04-0.10	1.00	2.00	0.045	0.03	8.0-10.0	18.0-20.0	-	-	-
321	0.08	1.00	2.00	0.045	0.03	9.0-13.0	17.0-19.0	-	-	Ti≥5*C%
347	0.1	1.00	2.00	0.045	0.03	9.0-13.0	17.0-19.0	-	-	Nb: 8C-1.10
631(J1)	0.09	1.00	1.00	0.040	0.03	6.5-8.5	16.0-18.0	-	-	Al: 0.75-1.5
NOTE: The single value represents the max. (Above tables)
Delivery condition and mechanical properties follow JIS/ASTM/DIN/GB standard

Welding Wire MIG

Grade: ER 307Si, ER308, ER308L, ER308LSi, ER309L, ER309LSi, ER316LSi, ER310, ER347, ER410, ER430, ER430LNb, ER630, ER2209, ER304

Wire Diameter: 0.8mm-1.6mm

Package: 1kg/box, 15kg/box, 20kg/box, 100kg/bucket, 200kg/bucket

Welding Wire SAW

Grade: ER308, ER308L, ER309L, ER310, ER316L, ER321, ER347, ER2209, ER304, ER410, ER430

Wire diameter: 1.6mm-4.0mm

Package: 25kg/box

Welding Wire TIG

Grade: ER308, ER308L, ER309L, ER310, ER316L, ER321, ER347, ER410, ER430LNb, ER630, ER2209, ER304

Wire Diameter: 0.8mm-5.0mm

Package: 5kg/box

Welding Wire FCW

Grade: TFS-307, TFS-308, TFS-308H, TFS-308L, TFS-308LD, TFS-309H, TFS-309L, TFS-309LMo, TFS-316H, TFS-316L, TFS-317L, TFS-347H, TFS-347L, TFS-2209, TFS-2594, TFS-410NM, TFS-409Ti, TCS-439Ti

Wire Diameter: 0.9mm, 1.0mm, 1.2mm, 1.6mm

Package: 12.5kg/box
